Dlink
D-Link DMC-810SSC 10/100/1000BASE-T D-Link DMC-810SSC
One/Two channel 10/100/1000 Mbps Ethernet to 10/100 Mbps bre optic conversion.Plug-and-Play, no additional software required
Visit our store and enjoy:
- Genuine, brand new, sealed stock
- Price-match against authorized dealers
- Installation & configuration services available
- Expert advice on compatibility with your network
KSh 8,800.00 KSh 9,800.00
D-Link DMC-810SSC 10/100/1000BASE-T Gigabit Twisted-pair to 1000BASE-LX Gigabit Fiber
Description
This Media Converter can be used by itself or installed in a chassis and converts between 1000BASE-T Gigabit twisted-pair signals to 1000BASE-LX Gigabit single-mode fibre signals.
The DMC-810SC converts 1000BASE-T Gigabit twisted-pair signals to 1000BASE-LX Gigabit single-mode fibre signals. Maximum fibre cable distance is 10 km. 1 RJ-45 port and 1 fibre port (SC type connector) are provided.
The DMC-700SC can be used as stand-alone device or as a module installed in the DMC-1000 chassis. The media converter is housed in a solid metal case and comes with status LEDs and an external AC power adapter. If you install it in the DMC-1000 chassis, remove its metal case and slide its PC board into an open slot in chassis. In this application, the chassis provides power for all media converters inside it, and the media converter’s own external AC power adapter will not be necessary.
Specifications
Dimensions 95 x 70 x 26 mm Power Input 5 V/1 A external power adapter Operation Temperature 0 °C to 60 °C Storage Temperature -20 °C to 70 °C Humidity 5 % to 90% RH, non-condensing Emission (EMI) • FCC• CE• VCCI LED Indicators “Power (PWR) LINK/ACT”
Technical Specifications
LED Indicators
- Power (PWR)
- LINK/ACT
Dimensions
- 120 x 88 x 25 mm
Power Input
- 7.5V 1.5A
- Through external AC power adapter
Operating Temperature
- 0° – 40° C
Storage Temperature
- -25° – 70° C
Humidity
- 10 ~ 90% non-condensing
Emission (EMI)
- FCC Class B
- VCCI Class B
- CE Class B
- C-Tick
- Fast and Easy to Use
- One/Two channel 10/100/1000 Mbps Ethernet to 10/100 Mbps bre optic conversion
- Plug-and-Play, no additional software required
- Can be used standalone or installed in the DMC-1014 chassis
- Half or full-duplex operation
- Auto-MDI/MDIX
Easy Placement and Monitoring
- Mount up to 14 media converters in the specially designed DMC-1014 Media Converter Chassis
- Dedicated power supply for powering the chassis and all installed media converters
- Hot-swappable when mounted
- Front panel LEDs for instant status feedback
